Name: 4 in. Pipe Size - Socket Weld Flange - Schedule 40 - 8 Bolt Holes - 150# ANSI Raised Face (RF) 316/316L Stainless Steel Forged Flange
Brand: BFO Select
SKU: 5504-X
Price: 244.82 USD
Availability: InStock

4 in. Pipe Size - Socket Weld Flange - Schedule 40 - 8 Bolt Holes - 150# ANSI Raised Face (RF) 316/316L Stainless Steel Forged Flange

(No reviews yet) Write a Review

SKU:

5504-X

Availability:

Available

Weight:

13.00 LBS

Description
Additional Information
0 Reviews
Reviews
Questions & Answers

Description

Material Specifications:

150# ANSI RAISED FACE SOCKET WELD SCH 40 - FORGED STAINLESS STEEl FLANGES

Raised Face (RF) 1/16"
Forged stainless steel material conforms to ASME A182
Forged stainless steel flange dimensions conform to ASME B16.5
304/304L & 316/316L Stainless Steel Available
Manufacturing facility is ISO 9001:2008
From Import
MTR and COC available
* Product images are for visual reference only and are not size specific *
For size specific product data and dimensions - view technical data sheet

End Connection/Schedule:

Socket Weld - Schedule 40 Pipe

Applications:

For use with schedule 40 pipe

Standards Met:

ASME A182 (Forging); ASME B16.5 (Dimensions)

COC Available:

COC - Yes
MTR - Yes

Additional:

Country of Origin:
From Import (S. Korea, Thailand, Vietnam, Subject to Change)

PDF/ Specs / Brochure

Socket Weld Flanges - Schedule 40/80 Data Sheet

View AllClose

Additional Information

Size (inches):	4.00 (4")
Material Type:	316/316L Stainless Steel
Schedule:	40
Product Type:	Socket Weld Flange
Category Type:	Pipe Flanges
Pressure Rating (psi):	150
Number of Bolt Holes:	8
Style:	Raised Face
Specifications or Standards:	ANSI
Specifications or Standards:	ASME A182
Specifications or Standards:	ASME B16.5
Weight (lbs):	13
Additional:	From Import
