BFO Select
1 in. NPT Threaded - Recessed Drop Coupling - 150# Cast 304 Stainless Steel Pipe Fitting
(No reviews yet)
Write a Review
- SKU:
- BF29DC14010
- MPN:
- 29DC14010
- Availability:
- Available
- Weight:
- 0.71 LBS
Description
Material Specifications:
- Drop pipe couplings are NPT (tapered threaded)
- Use with air, water, oil, natural gas, steam
- NPT and FNPT threads conform to ASME B1.20.1
- Maximum Pressure: 300 psi @ 72°F; 150 psi @ 366°F for steam
- Maximum Steam Pressure: 150 psi
- Stainless castings conform to ASTM A351 ACI Grade CF8 (304) & ACI Grade CF8M (316)
- Manufacturing facility is ISO 9001:2008
End Connection:
NPT Threaded - ASME B1.20.1
Applications:
Use with air, water, oil, natural gas, steam
MTRS / COC Available:
Both available upon request at time of order
Additional:
Schedule B 7307.29.0090
ECCN 2B999
Country of Origin:
From Import (varies - subject to change - China/Phillipines/Taiwan/Other)
PDF/ Specs / BrochureAdditional Information
Size (inches): |
1.00 (1") |
Material Type: |
304 Stainless Steel |
Product Type: |
Drop Coupling |
Category Type: |
Pipe Fittings |
Pressure Rating (psi): |
150 |
End Connection: |
NPT |
Specifications or Standards: |
ASME B1.20.1 |
Specifications or Standards: |
ISO Industry Standard |
Weight (lbs): |
0.71 |
Additional: |
From Import |
Industry Crossover: |
29DC14010 |
